RadioMaster TX16S MKII MAX EdgeTX RC Transmitter w/ AG01 Hall Gimbals – Carbon Fiber Black ELRS

Unmatched Upgrades for Enhanced Performance

The TX16S Max from RadioMaster has received revolutionary upgrades that elevate its functionality and style. Topping the list of enhancements is the inclusion of ExpressLRS as a standard feature, directly integrated from the factory. This advanced protocol ensures seamless communication, improved range, and quicker response times, making it an ideal choice for professional pilots and hobbyists alike. If you’re seeking a reliable and performance-driven remote controller, the TX16S Max won’t disappoint.

Premium Design with Colorful Options

The fresh upgrade isn’t limited to internal features alone; the TX16S Max brings a burst of individuality with multiple vibrant color options, catering to diverse preferences. Whether you prefer bold, statement hues or neutral tones, you’re sure to find a design that resonates with your personal taste. The attention to detail and quality materials shine through, making the TX16S Max a true standout in both appearance and performance.

AG01 Gimbals: A Game-Changer

One of the most celebrated features of the TX16S Max is the inclusion of AG01 gimbals. Perfectly engineered for precision and durability, these high-end gimbals set a new standard in consistency and control. With exceptional build quality and smooth operation, the AG01 gimbals provide effortless precision, whether you’re flying a drone, helicopter, or RC airplane. For those looking to up their game, these gimbals redefine user experience and control.

If you’re in the market for a remote controller that combines cutting-edge technology, aesthetics, and unmatched performance, the TX16S Max is the ultimate upgrade. Now with ExpressLRS onboard, jaw-dropping color options, and the remarkable AG01 gimbals, this device offers unparalleled value for every enthusiast.

Support EdgeTX and OpenTX

EdgeTX is installed by default (Touch screen enabled).

* Requires EdgeTX version 2.6.0 or OpenTX version 2.3.15 or later.

Available in 4in1 and ELRS versions

AG01 GIMBALS

AG01 Gimbal is fully CNC milled for ultimate precision with quad ball bearings for a smooth and precise feel. Featuring front-accessible tension and travel adjustment for easy fine-tuning.

Flat & Raised Grips Included

Both the raised and flat versions of the rear grips are included allowing you to customize the feel of your TX16s MKII right out of the box.

External Module Bay

The TX16s natively supports Team Black Sheep MicroTX modules in CRSFmode with LUA scripts. Best of all the TX16s Internal 4-in-1 Multi-protocol module allows you to keep the MicroTX installed and switch between internal RF and Crossfire via software, no more module swapping.

Easy Firmware Updates

Upgraded Design

• Retooled faceplate with improved fit and finish
• Improved S1/S2 knobs with center detents
• 4.3” IPS Color Display – The TX16s features a bright and clear 4.3-inch IPS color display for easy and convenient model setup and operation with adjustable brightness to suit all conditions.

• Improved LS/RS Sliders with smoother feel and better center-detents.

• New 3.5mm Audio jack – Rear mounted audio jack minimizes RF interference from external modules and adds headphone audio feature.
• Redesigned battery cover, easier to remove.
• Rear DIY Socket added for personalized mods.

Radio Overview

Features:

• Improved internal circuity and optimized power supply.
• New charge circuitry with integrated reverse-polarity protection.
• Optimized charge IC now allows up to 2.2A internal USB-C charge current.
• Rear mounted audio jack provided headphone output.
• V4.0 Gimbal improved centering and temperature stability (Same circuitry as AG01).
• Optional high/low rear grips included for improved ergonomics.
• Improved S1/S2 knobs with clear centre-detents.
• Improved LS/RS Sliders with smoother feel and better centre-detents.
• Redesigned battery cover for improved battery access.
• Retooled body shell with improved fit and finish.
• Trainer socket changed to standard TRS 3.5mm socket.
• Rear DIY Socket added for personalised mods.
• Improved internal plastics for better longevity.
• Available ELRS and 4in1 versions.

Specifications:

• Size: 287x129x184mm
• Weight: 750g (without battery)
• Transmission frequency: 2.400GHz-2.480GHz
• Transmitter module: Option 1: Internal 4-in-1 multi-protocol module (CC2500 CYRF6936 A7105 NRF2401)； Option 2: Internal ELRS (SX1280)
• Transmitting power: Internal 4-in-1 multi-protocol module : Max 100mw (protocol dependent); Internal ELRS : Max 250mw (transmitting power is adjustable)
• Antenna gain: 2db (transmit power adjustable)
• Working current: 400mA
• Working voltage: 6.6-8.4v DC
• Remote control distance:> 2km @ 22dbm
• Radio firmware: EdgeTX
• Channels: Up to 16 channels (depending on the receiver)
• Display: 4.3-inch TFT full-colour touch display with a resolution of 480 * 272
• Gimbal: AG01 CNC Hall sensor
• Module Bay: JR compatible module bay
• Upgrade method: Supports USB-C online / SD card offline upgrade

Includes:

• 1 x RadioMaster TX16S MKII MAX EdgeTX RC Transmitter w/ AG01 Hall Gimbals – Choose Version
• 1 x 18650 Tray
• 1 x USB-C Cable
• 1 x Screen Protector
• 2 x Flat Grips
• 2 x Raised Grips
• 1 x TX16S Key Chain
